Въглероден филтър
LED displejs
Осветление: халогенно
| Accessories - | Air flaps Yes | Delay Yes |
| Dimmer Yes | FrameOn Yes | Maximum time of delay 90 ' |
| Panel - language version Pictograms | Protection class of electric shock I_Class | Type of work Extraction/Recirculation |
| Number of carbon filters 1 | Number of grease filters 1 | Number of layers in grease filter 3 |
| Number of speed 3 | Type of control Sensor | Type of display LED |
| Type of grease filters Aluminium frame | Carbon filter type FWK 202 |
| Air flow at 1 speed - extractor by EN 61591 117 m3/h | Air flow at 2 speed - extractor by EN 61591 189 m3/h | Air flow at 3 speed - extractor by EN 61591 343 m3/h | |||||||||||||||||||||||||||
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 343 m3/h | Air Flow at Minimum Speed in Normal Use 117 m3/h | Air Flow Rate at Best Efficiency Point - Q BEP 186.6 m3/h | |||||||||||||||||||||||||||
| Air Pressure at Best Efficiency Point P BEP 164 Pa | Ikgadējais elektroenerģijas patēriņš 65.4 kWh | Average Illumination of the Lighting System on the Cooking Surface - E middle 186 lux | |||||||||||||||||||||||||||
| Control panel on one side/two sides One side | Country of Origin on Rating Label Made in EU | Dimensions of grease filter 222.5 x 250 x 9 mm | |||||||||||||||||||||||||||
| Display color Red | Distance from light cover to wall 10 mm | Distance to electric hob 450 mm | |||||||||||||||||||||||||||
| Distance to gas hob 650 mm | Electric Power Input at Best Efficiency Point - W BEP 100.7 W | Šķidrumu dinamikas efektivitāte 8.4 | |||||||||||||||||||||||||||
| Šķidrumu dinamikas efektivitāte E | Grease Filtering Efficiency - GFE hood 68.6 % | Tauku filtrēšanas efektivitāte D | |||||||||||||||||||||||||||
| Internal/external motor Internal | Apgaismojums 46.5 lux/W | Apgaismojuma efektivitātes klase A | Apgaismojums A | Maximum Possible Air Flow 343 m3/h | Motor unit rated power 115 W | Motor type/model K-28 030 00 HE | Net depth 385 mm | Net height max 1025 mm | Net height min 825 mm | Neto svars 12.46 kg | Net width 600 mm | Trokšņu līmenis 46 dB | Trokšņu līmenis 51 dB | Trokšņu līmenis 62 dB | Nominal Power of the Lighting System - W L 4 W | Number of motor units 1 | Number units of main lighting 2 | Gaisa izplūdes caurules diametrs 150 mm | Type of plug or cable Euro plug | Power Consumption in Standby Mode - Ps 0.25 W | Strāvas kabeļa garums 170 cm | Maksimālā jauda 119 W | Barošanas spriegums 230V | Power unit of main lighting 2 W | Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 62 dB | Sound Power Emission at Minimum Speed Available in Normal Use 46 dB | Trokšņu līmenis 62 dB | Time Increase Factor - f 1.7 | Type of main lighting LED |
Въглероден филтър
Чиста и ефективна екстракция на въздуха благодарение на интегрираните въглеродни филтри. (* въглеродният филтър се продава отделно).
LED displejs
Tikai vienreiz paskatoties uz displeju, iespējams uzzināt visu par tvaika nosūcēja iestatījumiem – kāds ir jaudas līmenis vai kad tas izslēgsies.
Нашите абсорбатори са оборудвани с халогенно осветление. Във всички модели включването на осветлението е независимо от действието на абсорбатора. Резултатът е удобство за потребителя.
Благодарение на използването на сензорно управление панелът за управление е много лесен за обслужване и мониториране.
